Contactor Application:
Resistive Load
Coil Voltage:
600 V
Pole and Throw Configuration:
3P
Width:
55 mm
Contact Current:
50A
Control Circuit Voltage Uc:
600 V
Function:
Changeover Contactor
Operational Current Ie:
50A
Product Type:
Contactor
Maximum Operating Temperature:
70°C
Terminal Type:
Everlink BTR Screw Connector
Length:
15.2cm
Standards/Approvals:
UL 508, IEC 60947-5-1, IEC 60947-4-1, IEC 60335-1, EN 60947-5-1, EN 60947-4-1, CSA C22.2 No. 14
Number of Auxiliary Contacts:
1
Auxiliary Contact Configuration:
1 NO/1 NC
Mount Type:
Plate
Better World Product:
Yes
Series:
LC1D
Depth:
120mm
Normal State Configuration:
1 NO/1 NC
Contact Voltage:
690V
Power Rating:
15kW
Number of Poles:
3
Minimum Operating Temperature:
-40°C
Coil Voltage:
600VAC
Termination Style:
Screw Terminal
Operating Temperature:
-40°C ~ 70°C
Coil Resistance:
-
Switching Voltage:
690VAC, 300VDC - Max
Coil Power:
-
Must Operate Voltage:
510 VAC
Manufacturer:
Schneider Electric
Contact Form:
3PST-NO (3 Form A)
Operate Time:
26 ms
Must Release Voltage:
180 VAC
standardLeadTime:
5 Weeks
Contact Rating (Current):
50 A
Features:
Auxiliary Contacts
Mounting Type:
Chassis Mount, DIN Rail
Series:
TeSys
Release Time:
19 ms
Packaging:
Box
Contact Material:
-
