Tesys D LC2D 3 Pole Contactor, 12 A, 5.5 kW, 24 V dc Coil

LC2D12BD Tesys D LC2D 3 Pole Contactor, 12 A, 5.5 kW, 24 V dc Coil
LC2D12BD
LC2D12BD
LC2D12BD Tesys D LC2D 3 Pole Contactor, 12 A, 5.5 kW, 24 V dc Coil
Schneider Electric

Product Information

Function:
Reversing
Better World Verification:
Green Premium
Better World Product:
Yes
Maximum Operating Temperature:
+50°C
Contact Current Rating:
12 A
Series:
LC2D
Minimum Operating Temperature:
-25°C
Coil Voltage:
24 V dc
Length:
77mm
Width:
90mm
Depth:
95mm
Number Of Auxiliary Contacts:
2
Normal State Configuration:
3NO
Range:
TeSys D
Power Rating:
5.5 kW
Contact Voltage Rating:
690 V ac
Number of Poles:
3
Terminal Type:
Screw
Coil Voltage:
24VDC
Termination Style:
Screw Terminal
Operating Temperature:
-40°C ~ 70°C
Coil Resistance:
-
title:
LC2D12BD
Coil Power:
-
Must Operate Voltage:
16.8 VDC
Manufacturer:
Schneider Electric
Contact Form:
3PST-NO (3 Form A)
Operate Time:
72.45 ms
Must Release Voltage:
2.4 VDC
standardLeadTime:
5 Weeks
Contact Rating (Current):
12 A
Features:
Auxiliary Contacts, Diode
Mounting Type:
Chassis Mount, DIN Rail
Series:
TeSys
Switching Voltage:
690VAC, 300VDC - Max
Release Time:
24 ms
Packaging:
Box
Contact Material:
-
RoHs Compliant
Checking for live stock

Tesys D Reversing Contactors Screw clamp connection Switching Category AC3 DIN rail mounting Only compatible with Tesys overload relays Operating temperature range -20 to +60°C Note Stock numbers 609-0289 and 609-0324 are low consumption 24Vdc variants. Approvals EN 60947, VDE 0660

pdf icon
Product Environmental Profile(Technical Reference)
pdf icon
Product Change Notice (PCN)(Technical Reference)
pdf icon
Datasheet LC2D12BD(Technical Reference)
