Contactor Application:
Reversing, Direct-on-Line (DoL), Motor Control
Coil Voltage:
24 V
Pole and Throw Configuration:
3P
Width:
45 mm
Contact Current:
12A
Distrelec Product Id:
302-27-124
Control Circuit Voltage Uc:
24 V
Function:
Safety
Operational Current Ie:
12A
Product Type:
Contactor
Maximum Operating Temperature:
60°C
Terminal Type:
Screw
Minimum Operating Temperature:
-25°C
Length:
81mm
Standards/Approvals:
CCC, CE, CSA, cULus, EAC, IEC, RoHS, UL
Number of Auxiliary Contacts:
5
Auxiliary Contact Configuration:
2 NO/3 NC
Mount Type:
Panel
Series:
100S-C
Depth:
125.5mm
Normal State Configuration:
2 NO/3 NC
Contact Voltage:
690V
Power Rating:
7.5kW
Number of Poles:
3
