Contactor Application:
Control Circuit
Coil Voltage:
24 V
Pole and Throw Configuration:
5
Width:
45 mm
Contact Current:
10A
Control Circuit Voltage Uc:
24 V
Function:
Control Relay
Product Type:
Contactor
Maximum Operating Temperature:
60°C
Terminal Type:
Spring Terminal
Length:
99mm
Standards/Approvals:
UKCA, UL 60947-5-1, UL, RoHS, REACH, JIS C8201-5-1, GB/T 14048.5, EN/IEC 60947-5-1, EAC, CSA C22.2 No 60947-5-1, CSA, CE, CCC, CB scheme
Number of Auxiliary Contacts:
5
Auxiliary Contact Configuration:
3 NO/2 NC
Mount Type:
Rail, Plate
Better World Product:
Yes
Series:
CAD
Depth:
95mm
Normal State Configuration:
3 NO/2 NC
Contact Voltage:
690V
Number of Poles:
5
Minimum Operating Temperature:
-5°C
Must Release Voltage:
2.4 VDC
Coil Voltage:
24VDC
Termination Style:
Spring Terminal
Operating Temperature:
-40°C ~ 60°C
Approval Agency:
CB, CCC, CE, CSA, EAC, UKCA, UL
Coil Type:
Non Latching
title:
CAD323BL
Seal Rating:
-
Must Operate Voltage:
16.8 VDC
Relay Type:
General Purpose
Load - Max Switching:
-
Contact Form:
5PST-3NO/2NC (3 Form A, 2 Form B)
Operate Time:
88 ms
Qualification:
-
standardLeadTime:
5 Weeks
Contact Rating (Current):
10 A
Features:
-
Mounting Type:
Chassis Mount
Grade:
-
Series:
TeSys
Switching Voltage:
690VAC - Max
Release Time:
42 ms
Packaging:
Box
Coil Insulation:
-
Contact Material:
-
