Dimensions:
277 x 88 x 43mm
Power Source:
Battery
DC Current Measurement Resolution:
100mA
Maximum Conductor Size:
277mm
DC Current Measurement Range:
999.9 A
AC Current Measurement Range:
999.9 → 2500 A
Width:
88mm
Resistance Measurement Resolution:
100mΩ
AC Current Measurement Resolution:
100mA
True RMS:
Yes
AC Voltage Measurement Range:
600 → 1000 V
Absolute Maximum AC Voltage Measurement:
1000V ac
Model Number:
381
Best AC Voltage Accuracy:
±1.5% +5 Digits
Absolute Maximum AC Current Measurement:
2500A ac
Battery Type:
AA
Absolute Maximum Resistance Measurement:
60kΩ
Maximum Operating Temperature:
+50°C
Jaw Capacity Busbars:
43mm
Safety Category Level:
CAT IV, CAT III
Length:
34mm
Calibrated:
RSCAL
Absolute Maximum DC Current Measurement:
999.9A dc
Display Type:
LCD
Best Resistance Measurement Accuracy:
±1% +5 Digits
Best DC Current Accuracy:
±2% +5 Digits
Weight:
540g
AC Voltage Measurement Resolution:
100mV
Best AC Current Accuracy:
±2% +5 digits
Safety Category Voltage:
600 V, 1000V
Absolute Maximum DC Voltage Measurement:
1000V dc
Height:
50mm
Safety Category:
CAT III 1000 V, CAT IV 600V
Best DC Voltage Accuracy:
±1% +5 Digits
DC Voltage Measurement Resolution:
100mV
Clamp Meter Type:
AC-DC Flexible Clamp Meter
Minimum Operating Temperature:
-10°C
Functions Measured:
AC Current, AC Voltage, Continuity, DC Current, DC Voltage, Frequency, Resistance
