Number of Contacts:
8
Orientation:
Straight
IP Rating:
IP67, IP65
Connector Size:
M12
Series:
VS
Coding:
Y
Contact Gender:
Female
Current:
6A
Plug/Socket:
Socket
Standards/Approvals:
CAT5 (IEC 11801:2002), cUL Recognised, RoHS II, UL Recognised
Voltage:
50 V
Contact Plating:
Gold
Termination Type:
Solder
Product Type:
Circular Connector
Maximum Operating Temperature:
85°C
Minimum Operating Temperature:
-40°C
Contact Material:
Copper Zinc Alloy
HTSUS:
8536.69.4020
RoHS Status:
ROHS3 Compliant
Mounting Feature:
Bulkhead - Rear Side Nut
Operating Temperature:
-40°C ~ 85°C
Shell Size, MIL:
-
Number of Positions:
8 (4 Data + 4 Power)
Contact Finish - Mating:
Gold
Backshell Material, Plating:
-
Shielding:
-
Cable Opening:
-
Shell Material:
Zinc Die Cast
REACH Status:
REACH Affected
Current Rating (Amps):
0.5A, 6A
Applications:
-
Primary Material:
Metal
Material Flammability Rating:
UL94 V-0
Voltage Rating:
30V
Shell Size - Insert:
M12-8
Connector Type:
Receptacle, Female Sockets
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Push-Twist
Termination:
Solder
standardLeadTime:
10 Weeks
Insert Material:
Polyphthalamide (PPA)
Orientation:
Y
Ingress Protection:
IP67 - Dust Tight, Waterproof
Features:
-
Mounting Type:
Panel Mount, Through Hole
Shell Finish:
Nickel
Color:
Silver
Series:
DSIV
Packaging:
Bulk
Contact Finish Thickness - Mating:
-
Contact Material:
Copper Zinc
ECCN:
EAR99
