Contact Material:
Copper Zinc Alloy
Number of Contacts:
5
Housing Material:
Polyamide
Pole Format:
5
IP Rating:
IP65, IP67, IP69K
Connector Size:
M12
Series:
SACC
Coding:
A
Contact Gender:
Female
Current:
4A
Plug/Socket:
Socket
Standards/Approvals:
cUL Recognised, IEC 61076-2-101, UL Recognised
Voltage:
48 V ac, 60 V dc
Contact Plating:
Gold
Shell Size:
M12
Product Type:
Industrial Circular Connector
Maximum Operating Temperature:
85°C
Minimum Operating Temperature:
-40°C
Mount Type:
Cable
HTSUS:
8536.69.4020
RoHS Status:
ROHS3 Compliant
Mounting Feature:
-
Operating Temperature:
-40°C ~ 85°C
Shell Size, MIL:
-
Number of Positions:
5
Backshell Material, Plating:
Polyamide (PA), Nylon
Shielding:
-
Cable Opening:
0.236" ~ 0.315" (6.00mm ~ 8.00mm)
title:
1553307
Shell Material:
Stainless Steel
REACH Status:
REACH Affected
Current Rating (Amps):
4A
edacadModel:
1553307 Models
Applications:
-
Contact Finish - Mating:
Gold
Primary Material:
Metal
Material Flammability Rating:
-
edacadModelUrl:
/en/models/3607078
Voltage Rating:
48VAC, 60VDC
Shell Size - Insert:
M12-5
Connector Type:
Receptacle, Female Sockets
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Threaded
Termination:
Screw
standardLeadTime:
4 Weeks
Insert Material:
Polyamide (PA), Nylon
Orientation:
A
Ingress Protection:
IP65/IP67/IP69K - Dust Tight, Water Resistant, Waterproof
Features:
Backshell, Coupling Nut
Mounting Type:
Free Hanging (In-Line), Right Angle
Shell Finish:
-
Color:
Black, Silver
Series:
SACC
Packaging:
Bulk
Contact Finish Thickness - Mating:
-
Contact Material:
Copper Zinc
ECCN:
EAR99
